RADIATOR FOR HONDA REBEL 500 ABS 2024

TOOL

(1) 19010-MKG-T81

RADIATOR COMP. (T.RAD)

(2) 19014-KEA-003

NUT, SETTING(6MM)

(3) 19015-K87-A01

SHROUD COMP.

(4) 19016-KEA-003

SCREW, PAN, 4X8.5

(5) 19020-KVZ-631

FAN COMP, COOLING

(6) 19032-K87-A31

GRILLE, RADIATOR

(7) 19037-K15-921

CAP COMP., RADIATOR (T.RAD)

(8) 19046-K15-921

LABEL, RADIATOR CAP

(9) 19080-K87-A01

MOTOR ASSY., COOLING FAN

(10) 19101-K87-A00

TANK, RADIATOR RESERVE

(11) 19109-KBP-900

CAP, RESERVE TANK

(12) 19501-MKG-A00

HOSE, RADIATOR UPPER

(13) 19502-MKG-A00

HOSE, RADIATOR LOWER

(14) 19531-MJW-J00

--- GRIFFE DE FLEXIBLE D'EAU (D27)

(15) 19533-MJW-J00

--- GRIFFE DE FLEXIBLE D'EAU (D30)

(16) 61102-KTY-D30

COLLAR, RADIATOR MOUNTING

(17) 61304-415-000

RUBBER,HEADLIGHT C

(18) 90111-K87-A00

SCREW, SPECIAL, 6X14

(19) 90112-K87-A00

--- VIS SPECIALE, 6X25

(20) 90120-KCR-003

BOLT-WASHER, 6X16

(21) 90134-KPP-T00

SCREW,PAN 5X14

(22) 90303-MGZ-J40

NUT,CLIP 6MM

(23) 90315-MFL-003

--- ECROU DE BRIDE, 3MM

(24) 93901-22020

SCREW, TAPPING, 3X6

(25) 95002-02100

CLIP B10 TUBE

(26) 95002-50000

CLIP C9 (TUBE)

(27) 95005-5041030

--- TUBE, 5X410 (95005-50001-30M)

	Part number	Description	Qty
# 1	19010-MKG-T81 19010MKGT81 19010MKGT81	RADIATOR COMP. (T.RAD)	Contact	RM0,00
# 2	19014-KEA-003 19014KEA003 19014KEA003	NUT, SETTING(6MM)	RM6,68
# 3	19015-K87-A01 19015K87A01 19015K87A01	SHROUD COMP.	Contact	RM0,00
# 4	19016-KEA-003 19016KEA003 19016KEA003	SCREW, PAN, 4X8.5	RM2,01
# 5	19020-KVZ-631 19020KVZ631 19020KVZ631	FAN COMP, COOLING	RM113,42
# 6	19032-K87-A31 19032K87A31 19032K87A31	GRILLE, RADIATOR	Contact	RM0,00
# 7	19037-K15-921 19037K15921 19037K15921	CAP COMP., RADIATOR (T.RAD)	Contact	RM0,00
# 8	19046-K15-921 19046K15921 19046K15921	LABEL, RADIATOR CAP	Contact	RM0,00
# 9	19080-K87-A01 19080K87A01 19080K87A01	MOTOR ASSY., COOLING FAN	Contact	RM0,00
# 10	19101-K87-A00 19101K87A00 19101K87A00	TANK, RADIATOR RESERVE	Contact	RM0,00
# 11	19109-KBP-900 19109KBP900 19109KBP900	CAP, RESERVE TANK	RM2,33
# 12	19501-MKG-A00 19501MKGA00 19501MKGA00	HOSE, RADIATOR UPPER	Contact	RM0,00
# 13	19502-MKG-A00 19502MKGA00 19502MKGA00	HOSE, RADIATOR LOWER	Contact	RM0,00
# 14	19531-MJW-J00 19531MJWJ00 19531MJWJ00	--- GRIFFE DE FLEXIBLE D'EAU (D27)	Contact	RM0,00
# 15	19533-MJW-J00 19533MJWJ00 19533MJWJ00	--- GRIFFE DE FLEXIBLE D'EAU (D30)	Contact	RM0,00
# 16	61102-KTY-D30 61102KTYD30 61102KTYD30	COLLAR, RADIATOR MOUNTING	Contact	RM0,00
# 17	61304-415-000 61304415000 61304415000	RUBBER, HEADLIGHT C	RM1,59
# 18	90111-K87-A00 90111K87A00 90111K87A00	SCREW, SPECIAL, 6X14	Contact	RM0,00
# 19	90112-K87-A00 90112K87A00 90112K87A00	--- VIS SPECIALE, 6X25	Contact	RM0,00
# 20	90120-KCR-003 90120KCR003 90120KCR003	BOLT-WASHER, 6X16	Contact	RM0,00
# 21	90134-KPP-T00 90134KPPT00 90134KPPT00	SCREW, PAN 5X14	RM2,33
# 22	90303-MGZ-J40 90303MGZJ40 90303MGZJ40	NUT, CLIP 6MM	RM2,33
# 23	90315-MFL-003 90315MFL003 90315MFL003	--- ECROU DE BRIDE, 3MM	Contact	RM0,00
# 24	93901-22020 9390122020 9390122020	SCREW, TAPPING, 3X6	RM1,27
# 25	95002-02100 9500202100 9500202100	CLIP B10 TUBE	RM1,27
# 26	95002-50000 9500250000 9500250000	CLIP C9 (TUBE)	RM1,59
# 27	95005-5041030 950055041030 950055041030	--- TUBE, 5X410 (95005-50001-30M)	Contact	RM0,00

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Honda. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the RADIATOR of your Honda REBEL 500 ABS of REBEL. Let us know if you have any questions.
